Model: LS 9070 W

Wet Blasting is similar to Dry Blasting. Wet-Blasting use mixing a dry abrasive with water through either Water Injection Nozzles, Halo Nozzles, Wet Blast Rooms or Modified Blast Pots. The Advantages Of Wet Blasting are Less Dust (due to the use of water, wet blasting reduces the amount of dust produced by the abrasive blasting process), more protection to operator, hydrostatic forces (the presence of water means that there is more mass at the point of impact and may require less abrasive), and cleaner. Wet Blasting process will consume water during the process, higher cost due to water pumping, mixing and reclamation systems, plus the requirement for containment and drainage can increase the costs of wet blasting and the amount of equipment required, and producing wet waste.
By wet-blasting process, we can clean the grease and dirt. Wet Blasting process will not change the surface color on the workpiece due to temperature during the blasting process. The WetBlasting is more suitbale for micro powder sandblasting media, which is higher than #400 such as precision moild, electronic parts, piston ring, aviation parts, surface pretreatment of titanium plate, circular saw blade etc.



The cabin for wet-blasting can be made of glass fiber, reinforced plastic or stainless steel to avoid corrosion.



Model & Specification

Cabin size (mm) & structure

Max bearing capacity (KG)

Storage box capacity

Abrasive Pump

Compressed air-supply

Model:
LS 686 W

680 x 680 x 600

4mm-thick glass reinforced plastic

20 KG

25L water with 2-4 kg abrasive media

Polyurethane
pump driven by 550W

2.1 – 5 bar

Wet type sandblasting cabinet

Model:
LS 9070 W

900 x 700 x 600

4mm-thick glass reinforced plastic

20 KG

30L water with 3-5 kg abrasive media

Polyurethane
pump driven by 750W

3 – 7 bar

Wet type sandblasting cabinet

Model:
LS 9090 W

900 x 900 x 600

4mm-thick glass reinforced plastic

20 KG

30L water with 3-5 kg abrasive media

Polyurethane
pump driven by 750W

3 – 7 bar

Wet type sandblasting cabinet



Door and window: Tempered glass door and window with pneumatic water wiper

Abrasive Feeding Type: Wearable Polyurethane Abrasive Pump

Spray Gun: high efficiency tungsten steel nozzles

Air flow: 0.4 – 1.0 m3/minute connect with ½” piping system

Water supply: industrial tap water with ½” hose adaptor

Power supply: single phase 220V, 50Hz
