Its manual & pneumatic control sandblasting pot with simple operation. It uses in marine repair, rust removal pipeing and tank, and also repaint the container. Its divided by manual pneumatic or electrical control and both with single/double silo and single/multi gun are available. It has option of mobile and fixed type.

ACME-3 A1

ACM-5 2A

ACM-4A Stainless Steel

ACME-1A Double Silo

ACM-5W-2A

ACMR E 52W-4A

ACM-5

ACME-42W-4A1

ACME 52W 2A Double Silo

Type/Size Drum dia (mm) Height (mm) Volume (m3) Model Loading Qty (Steel Grit) in kg Loading Qty (Sand) in kg

ACM (R) – 0P

350

900

80

1

304

104

ACM (R) – 1P

400

1100

150

1

570

195

ACM (R) – 3

750

1500

266

1

1360

470

ACM (R) – 3L

750

1700

363

1

1360

470

ACM (R) – 4

900

1800

490

1-2

1840

630

ACME-4W-4A

900

2300

1150

1

4180

1490

ACM (R) – 3P

750

1500

266

1

1360

470

ACM (R) – 3LP

750

1700

366

1

1360

470

ACM (R) – 5W

1200

2000

1000

1-2

4240

145

Remarks:

ACM = Manual control type

ACMR = Pneumatic control type

ACME = Electric control type

2A = 2 gun (nozzles)

P = wheel type

Blasting pot can be customized depending on requirement such as volume,
number of blasting gun, number of storage silo, control type etc.



Requirement of steel grit to process 1m2 blasting areais approx. 108 kg.

Requirement of air supply: need to be filtered by precision filter.



Meet the sandblasting quality criteria:

ISO 8501-1: cleanliness Sa 2.5

ISO 8503-1: Roughness Ra 25 – 125 µm

KPBM Series

Automatic SandBlasting Pot with Combo Process
